2 HP 1 Stage 5.5 CFM @ 90 PSI 2-Cylinder Air Compressor Pump Campbell Hausfeld VT4823
Regular price
$199.95
This two-cylinder, single-stage cast-iron air compressor pump is a direct-fit replacement for the Campbell Hausfeld VT4823 and many similar 2 HP compressor models. Designed for durability and reliable performance, this pump delivers up to 5.5 SCFM at 90 PSI, making it ideal for light-to-medium duty shop and home compressor applications.
Commonly used on compressor tanks up to 40 gallons, this pump is compatible with 110V or 220V 2 HP electric motors (or larger). It ships fully assembled and ready to install, including the intake filter and pulley shown in the product photos.
Specifications:
- Horsepower Rating: 2 HP
- Pump Type: Single Stage
- Cylinder Configuration: Two Cylinder
- Maximum Output: Up to 5.5 SCFM at 90 PSI
- Recommended Tank Size: Up to 40 Gallons
- Pump Material: Cast Iron Body with Aluminum Head
- Pulley Diameter: 10 inches
- Intake Port: 1/2 inch FNPT
- Discharge Port: 3/8 inch FNPT
- Oil Drain Location: Opposite Shaft Side
- Weight: 34 lbs
- Includes: Intake filter and pulley
Mounting Hole Dimensions Center to Center:
• Front to Back: 6-1/2"
• Side to Side: 5-7/8"
| Campbell Hausfeld | Speedaire | Kobalt | Husky |
| VT500188AJ | 4B222 | VT6361 | VT631505 |
| VT627700 | 4B232B | VT6389 | VT631505AJ |
| VT612902AJ | 4B233C | VT631506AJ | |
| VT619602 | 4B234C | VT635800 | |
| VT619602AJ | 4B227E | VT636700 | |
| VT629000 | 4TW29C | VT631538 | |
| VT619604 | 4B227C | VT631538AJ | |
| VT619604AJ | 4B228C | ||
| VT470000AV | 4B229B | ||
| VT470200 | |||
| VT203003 | |||
| VT480000AV | |||
Customers praised this 2 HP air compressor pump as an "exact replacement" for failed pumps, with "outstanding quality" and easy installation. Shoppers highlighted it's "quieter than the old one" and fits perfectly as a bolt-on replacement. All connections lined up properly, and customers appreciated getting "everything you need in one box."
Compressor (positive)Motor (positive)Connections (positive)Box (positive)Pump (positive)
K
I'm rebuilding a 1984 Speedaire 20-gallon horizontal. The pump uses the same hole pattern, bolted right up. The pump is putting out 5.82 cfm from empty tank to 120 psi. The pump is quiet, smooth running. I performed (3) twenty minute, no load break-in intervals which seated the rings nicely. I'm happy with it.
B
P just received my compressor pump exact bolt on changed out the pulley outstanding quality thank you so much would always buy you guys again
A
Fit right into spot of my old pump
A
Well after we received the replacement motor.
It works great all the nice getting everything you need in one box.
C
Great pop looks just like OEM took only minutes to replace
K
Working fine and quieter than the old one.
M
Working good and quiet
J
This was an exact replacement for my failed air compressor pump. Everything was as described, and all the connections lined up perfectly.
A
Perfect fit for my old speed air compressor. That’s 25 years old runs like a brand new one now.
