2 - 3 HP 1 Stage 12 CFM 2-Cylinder Air Compressor Pump LPV6546

Low stock: 5 available
SKU: LPV6546
$229.95
60-day returns No-hassle policy
US-based support Mon–Fri 8:30–4:30 CT
Same-day shipping Order by 3:00 PM CT
45+ years expertise Compressor specialists

3 HP Replacement Single Stage Air Compressor Pump

Brand new two-cylinder cast iron single stage air compressor pump. This is a 3 horsepower pump that will deliver 11.8 CFM at 1100 RPM with a max RPM of 1400. This pump is most commonly used on compressors under 60 gallons in size and can be used with a true 3 horsepower motor (these motors typically run at 15 amps on 230 volts). This pump comes complete as shown in the photos, including intake filter and pulley. See specifications below for more details.

Features:

• Cast Iron Cylinder and Crankcase
• Equipped with Sight Glass for Easy Viewing of Oil Level
• Comes with Two Intake Filters

Specifications

• Two Cylinder
• Single Stage
• Recommended Motor Size: 3 HP
• CFM at 1100 RPM: 11.8
• CFM at 1400 RPM (Max RPM): 15.1
• Cylinder Diameter: 65mm
• Cylinder Stroke: 46mm
• Pump Flywheel Diameter: 10.5"
• Working Pressure: 120 PSI
• Maximum Pressure: 150 PSI
• Net Weight: 55 lbs
• Outside Dimension: 15.36" x 11.42" x  13"
  • 5 stars: 1 (100%)
  • 4 stars: 0 (0%)
  • 3 stars: 0 (0%)
  • 2 stars: 0 (0%)
  • 1 star: 0 (0%)
J
John

I'm interested in your 3 HP pump. I have a DOERR 3 HP motor with a 2.5 inch pulley. The DOERR runs at 3450 rpm. Is my motor sufficient to run this pump? Thanks.

Compressor Source

Hi John!

Thanks for checking with us. A 3 HP motor is the right size for this pump, but there are two important details to check to ensure this setup runs smoothly:

Motor Power: Please verify your motor is a "true" 3 HP. A true 3 HP motor typically requires 230 volts and draws around 15 amps. If your motor is capable of running on standard 110/115 volts, it is likely not powerful enough for this heavy-duty pump.

Pulley Size: Your 2.5" pulley is slightly too small for a 3450 RPM motor. It will run the pump below its minimum recommended RPM, resulting in lower air output and poor lubrication. We recommend sizing up to a 3.25" pulley to get the pump spinning at the optimal speed.

Here is the pulley that would work best for your setup: https://compressor-source.com/products/3-25-cast-iron-single-groove-pulley-a-belt-4l-style-5-8-shaft#

If you have any additional questions, please feel free to call us at 402-261-9563 and ask for Dan or Ally!"
