EMAX 13 HP 2 Stage 30 Gallon Air Compressor Truck Mount EGES1330V4
Regular price
$4,555.00
We're an Authorized EMAX Dealer and Service Center: Call us at 402-261-9563 for buying support, technical questions and special orders from the EMAX catalog
The EMAX EGES1330V4 has been discontinued.
** Check out the EGES1330ZT for the recommened replacement ** .
13 HP 2 Stage 30 Gallon Truck Mount Air Compressor - 31 CFM
Introducing the EMAX Industrial 13 HP 2-Stage 30-Gallon Truck Mount Gas Powered air compressor, a powerful and portable solution designed for industrial-grade pneumatic applications. With a robust 13 HP gas engine and a two-stage pump, this compressor delivers consistent and reliable air supply for demanding tasks. Its compact and truck-mountable design makes it ideal for mobile operations, ensuring you have access to compressed air wherever your work takes you. Please see below for more features and specifications.
Features and Specifications:
• Pump Model: APP4V1043TP
• Pump Material: Cast Iron
• Pump RPM: 640
• CFM @ 100 PSI: 31
• Max PSI: 175
• Tank Size: 30 Gallons
• Tank Orientation: Horizontal/Truck Mount
• Overall Dimensions (LxWxH): 55" x 27" x 43"
• Weight: 695LBS
• Tank Outlet Size: 3/4" NPT
• Engine Make/Model: Honda GX 390
• Gas Tank Size: 1 Gallon
• Starting System: 12-Volt Button Start q/Recoil
• Certifications: CSA, ASME
